14 foot wall mounted maslow

Hardware
1

I wanted to share the progress on my metal frame for the Maslow. I don’t have my kit yet, but trying to be prepared for when it arrives.

Construction is 1-1/2" 16ga box section steel, mig welded together. The frame has a 14’ top beam, with 30" of separation between the beam and the work piece. I put supports in for a 1’ skirt around the work piece if needed. I just have the basic frame done so far:

20180901_111745
20180901_1117454032×3024 3.16 MB

20180901_160252
20180901_1602524032×3024 3.96 MB

20180902_144317
20180902_1443174032×3024 3.83 MB

20180902_131351
20180902_1313513024×4032 3.37 MB

20180904_222011
20180904_2220114032×3024 3.66 MB

Leveled using a cheap laser level

20180909_210441
20180909_2104414032×3024 4.03 MB

20180909_212535
20180909_2125354032×3024 2.71 MB

I had some help cleaning up the mess after clearing that corner of the garage for the frame :slight_smile: Most of the projects I want to do with the maslow will be things for them.

20180901_135115
20180901_1351154032×3024 3.46 MB

I still need to weld on hinges, and figure out the struts to keep it at 15 degrees.

6 Likes
2

It’s hard to see in the pictures, but does the top beam sit forward of the rest of the frame?

it looks like you’ve made the same mistake that several others have made recently, and made the top beam flush with the rest of the frame.

3

The pictures don’t show it well, but there is a 3" spacer between two 14’ pieces of box. From looking at the different frames, that seemed to be the common spacing. If i need to move it out further at some point, i will, but I figured that was a good starting point

Maybe this is a little clearer

20180909_210431
20180909_210431.jpg4032×3024 3.1 MB

5 Likes
4

this looks like the set up i am about to take on. i currently have a regular maslow set up and i wanted to make one that was capable of cutting edge to edge. these were the numbers i came up with as well. have you finished this set up yet and or had any success with it?
